VPP6T0 6305E
Entry 4K60 Encoder / Edge AI
Features
- Up to 8 TOPS AI Performance
- 1 Channel 4K60 Encode / Decode
- 2×M2 M Key / 1×M2 E Key / 1×M2 B Key
- 2×USB3.0 / 2×USB2.0
- 6×COM Port / 2×I2C
| System | |
|---|---|
|
CPU |
Intel® Celeron® 6305E |
| GPU |
Intel® UHD Graphics |
| API Performance | 8 TOPS |
| System Memory | 2×8GB DDR4 3200MHz Dual Channel |
| Interface | |
| Storage | 128GB M2 2280 SATA SSD 1×SATA |
| Display Interface |
Rear Display 2×HDMI2.0 |
| Ethernet | 2×RJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Expansion Slot |
PCIe 1×PCIe Gen3×4 Slot 1×PCIe Gen3×4 Slot ( Switch with M.2 M Key) M2 1×M2 2280 M Key PCIe Gen3×4 Slot ( Switch with 2nd PCIe ) 1×M2 3042 B Key USB3.0 Slot with SIM Card Slot 1×M2 2230 E Key PCIe Gen3×1/USB2.0 Slot |
| USB |
Front USB 1×USB3.0 ( Type-A ) Rear USB 1×USB3.0 ( Type-A ) 2×USB2.0 ( Type-A ) Internal USB 4×USB2.0 ( Pin Header ) |
| Audio |
1×3.5mm Line/MIC In 1×3.5mm Line Out |
| Peripherals |
6×COM Port ( Pin Header ) 2×I2C ( Pin Header ) |
| Misc. Features | With Option Front Panel Control Button ( Compatible with Stream Capture Pro ) |
