SC6G0 AV Data Bridge
| Model Name | SC6G0 AV Data Bridge |
| Max. FPS | 4096×2160p@60/50fps |
| Recording Mode | Hardware Compression |
| CPU | N/A |
| A/V Input Interfaces |
Video (Select One) 1×HDMI2.0 1×USB Type-C DP-ALT 1×UVC Audio 1×3.5mm stereo analog audio |
| A/V Output Interface |
Video (Select One) 1×HDMI2.0 1×UVC Audio 1×3.5mm stereo analog audio |
| Video Feature | N/A |
| Video Encode | N/A |
| Audio Feature |
AAC-LC Configurable bit rate range from 32Kbps to 384Kbps Sample rate : 48KHz, 16bit, Stereo |
| Network Feature | 1×RJ45 for 10/100/1000Mbps Ethernet |
| Support Streaming protocol |
NDI | HX ( Separate License with NDI Required ) Danta AV-H ( Separate License with Dante Required ) RTSP over UDP / TCP / Multicast / HTTP RTMP/RTMPS push *SRT **TS over IP **HLS ** optional by customer request |
| Misc. Features |
HDMI / DP-ALT / UVC / AV over IP Tri-directional video format convert Web UI for system configuration Mini USB2.0 for KVM LED indicator ( Power,Status,DP-ALT,HDMI ) 2×USB2.0 Type-A ( For mouse, Keyboard ) 2×USB3.0 Type-A ( For Storage ) |
| PGM mode switch | N/A |
| Support Record Device | N/A |
| SDK Support | N/A |
| AI Features | N/A |
| Record Format | N/A |
| Power Supply |
DC input : 12V Support POE |
