SC6G0N1 IP to UVC/HDMI2.0
4K60 IP to UVC/HDMI
| Model Name | SC6G0N1 IP to UVC/HDMI2.0 |
| Max. FPS | 3840×2160p@60/50fps |
| Recording Mode | Hardware Compression |
| CPU | N/A |
| A/V Input Interfaces |
Video 1×RJ45 |
| A/V Output Interface |
Video 1×HDMI2.0 1×USB3.0 Type B ( UVC ) output |
| Video Feature |
H.265 ( HEVC ) / H.264 / AVC, Baseline / Main / High Profile Configurable Bit Rate Up to 64Mbps Support input / output resolutions 3840×2160p@60/50fps 3840×2160p@30/25/24fps 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1280×720p@60/50fps 1280×1024p@60fps 1280×960p@60fps 1024×768p@60fps 800×600p@60fps 640×480p@60fps 720×480p@60fps 720×576p@50fps |
| Video Encode | N/A |
| Audio Feature |
AAC-LC Configurable bit rate range from 32Kbps to 384Kbps Sample rate : 48KHz, 16bit, Stereo |
| UVC output |
NV12 2160p30/25/24 YUY2/NV12 1080p60/50/30/25/24 720p60/50/30/24 640x480p30 320x240p30 MJPEG/H.264/H.265 2160p60/50 2160p30/25/24 1080p60/50/30/25/24 720p60/50/30/24 640x480p30 320x240p30 |
| Network Feature |
1×RJ45 for 10/100/1000Mbps Ethernet DHCP Client |
| Support Streaming protocol |
NDI Support ( Separate License with NDI Required ) RTSP over UDP / TCP / Multicast / HTTP RTMP public ( web portal ) **TS over IP **HLS ** optional by customer request |
| Misc. Features |
UVC Supported Web UI for System Configuration Firmware Upgradable |
| PGM mode switch | N/A |
| Support Record Device | N/A |
| SDK Support | N/A |
| AI Features | N/A |
| Record Format | MP4 / TS / MOV |
| Power Supply |
DC input : 12V PoE ( 802.3af ) |
