SC6T0N4 HDMI AI+

4CH HDMI 4KP30 ENCODER+DECODER+SWITCH+AI

SC6T0N4 HDMI AI+
Model Name SC6T0N4 HDMI AI+
Max. FPS 4096×2160p@30/25fps
CPU 11th Gen Intel® Core™ i7 1165G7 ( 2.8GHz )
5G Support LTE Cat20 ( Option )
LTE FDD Supported
LTE TDD Supported

Sub-6 ( Option )
SA Supported
Non-SA Supported
** Optional by Customer Request
A/V Input Interfaces Video
4×HDMI1.4

Audio
4×HDMI Embedded Digital Audio ( LPCM )
1×3.5mm Line/MIC in
A/V Output Interface Video
2×HDMI2.0 ( Multiview / PGM )

Audio
2×HDMI Embedded Digital Audio ( LPCM )
1×3.5mm Line out
Video Feature Support Input / Output Resolutions

4096×2160p@60/50fps ( Output Only )
3840×2160p@60/50fps ( Output Only )
4096×2160p@30/25/24fps
3840×2160p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Video Encode Support Resolutions

4096×2160p@30/25/24fps
3840×2160p@30/25/24fps
1920×1080p@60/50fps
1920×1080p@30/25/24fps
1920×1080i@60/50fps
1280×720p@60/50fps
1280×1024p@60fps
1280×960p@60fps
1024×768p@60fps
800×600p@60fps
640×480p@60fps
720×480p@60fps
720×576p@50fps
720×480i@60fps
720×576i@50fps
Audio Feature Configurable bit Rate Range from 32Kbps to 384Kbps
Sample Rate : 48KHz, 16bit, Stereo
Network Feature 2×RJ45 for 10/100/1000Mbps Ethernet
DHCP Client

**Wifi ( Option ) :
**802.11b/g/n
**802.11ac
** Optional by Customer Request
Support Streaming protocol NDI Support ( Separate License with NDI Required )
RTSP over UDP/TCP/Multicast/HTTP
RTMP Public ( web Portal )
**TS over IP
**HLS
** Optional by Customer Request
Misc. Features Firmware Upgradable
LED Indicator
2×USB3.0
2×USB2.0
Bluetooth Supported ( Option )
PGM mode switch PGM Mode Switch

Full Screen :
Quadview
Picture by Picture
Picture in Picture
PGM Loop
Full Screen Switch :
Channel 1
Channel 2
Channel 3
Channel 4
Support Record Device External USB3.0 HDD
Internal SATA 2.5" HDD
✻ HDD Not Included at SC6T0
SDK Support YUAN QCAP Video Capture SDK
YUAN QDEEP AI Algorithm SDK
Intel® Distribution of OpenVINO™ toolkit
AI Features Face Tracking
Background Effect
Extracting Handwriting
ePTZ
Customizable Video AI Functions Upon Request :
QDEEP AI SDK Integrated Multiple Algorithms and Deep-Learning Models in Various Fields of Applications.
Record Format N/A
Power Supply DC input : 19V
